Technical Specifications
|
Item |
Specification Range |
Description |
|
Substrate Type |
Hot-dip Galvalume Steel (GL) |
55% Al-Zn alloy coating, customizable coating weight |
|
Thickness |
0.12–3.0mm |
Customizable on demand |
|
Width |
40mm–1250mm |
Support customized cutting |
|
Alu-Zinc Coating |
AZ20-220 g/m² |
Adjustable according to anti-corrosion requirements |
|
Hardness |
CQ, Full hard, Soft, Middle Hard |
Adapt to different weather resistance requirements, optional high weather resistance coatings such as fluorocarbon |
| Composition | 55%Aluminum+45%Zinc | Al-Zn alloy coating composition by weight |
|
Standard |
ASTM A792, ASTM 653, etc |
Meet international general standards |
Galvalume coil is hot-dip coated steel finished with a 55% aluminum-zinc alloy - the chemistry that keeps it working where plain galvanized gives up. Aluminum builds a stable oxide that slows corrosion for roughly 2–4 times longer than zinc-only coating in coastal air, humidity, and thermal cycling, while the zinc fraction still protects cut edges sacrificially. Shear it, punch it, roll-form it: exposed edges keep their protection.
Wide Application Scenarios
Roofing and wall cladding for factories, warehouses, and farm buildings. The alloy coating resists corrosion in coastal and humid air and keeps roofs cooler under strong sun.
Cold-formed purlins, studs, and framing for portal sheds, mezzanines, and carports. The coil rolls, punches, and cuts cleanly at production speeds.
Prefabricated and modular buildings, sandwich panel facings, and container homes.
HVAC ducting and cable trays, where the coating tolerates moderate heat and humidity without flaking.
Appliance housings, electrical enclosures, and outdoor equipment panels that need a clean surface and long service life.
Solar mounting frames and agricultural structures - grain silos, livestock sheds - where scratched edges keep sacrificial protection from the zinc phase.
Strict Production Process
Substrate Pretreatment
Degreasing to remove residual surface oil → Phosphating to form compact phosphate conversion film → Passivation treatment to enhance coating adhesion and corrosion resistance
Multi-layer Roller Coating
Adopting continuous coil coating process, first apply epoxy primer for base protection, then topcoat for color and weather resistance, and back paint for reverse side protection
High-temperature Curing
Curing in a continuous baking oven at 200-240℃ to form a stable cross-linked network structure, ensuring coating adhesion and durability
Full Inspection Quality Control
Full inspection of coating uniformity, color difference, physical properties and salt spray corrosion resistance to ensure products meet international standards
Packaging & Delivery
|
Item |
Description |
|
Standard Packaging |
Waterproof paper + steel strip fixing + wooden pallet, ensuring safe transportation |
|
Minimum Order Quantity |
1 container, negotiable for trial orders |
|
Lead Time |
20-35 days (after payment, adjustable according to order quantity) |
|
Port of Loading |
Qingdao Port, Tianjin Port |
|
Payment Terms |
T/T, L/C and other flexible payment methods |
Authoritative Qualification Certification
ISO 9001 Quality Management System Certification
CE EU Safety Certification
SGS/BV Third-party Authority Test Report
RoHS & REACH Environmental Compliance Certification
FAQ
Integrity is our core tenet. No matter how the market price fluctuates, we will guarantee the delivery of qualified products on time.
You can provide the order demand, product specifications (steel type, size) and destination port, we will provide you with the latest quotation within 24 hours.
We can provide free samples, the sample freight is borne by the customer; if the cooperation is reached subsequently, the freight can be borne by our company.
