Product Overview
Our Corrugated PPGL Color Coated Aluzinc Steel Roofing Sheets represent the perfect fusion of advanced coating technology and premium steel manufacturing. Combining the exceptional corrosion resistance of aluzinc alloy with the vibrant, long-lasting protection of pre-painted coatings, these roofing sheets deliver outstanding performance across diverse environmental conditions.
Engineered for industrial, commercial, and residential applications, our roofing solutions offer customizable dimensions, extensive color options, and proven durability. Each sheet undergoes rigorous quality control to ensure consistent performance, making them the preferred choice for construction projects worldwide.
Products Description
Strong rust resistance built into the aluzinc alloy This coating forms a self-healing barrier. Aluminum blocks surface oxidation, while zinc protects cut edges and minor scratches made while installing on site. Our standard 150g/m² grade passed independent SGS salt spray testing with 1200 hours before red rust appeared-better performance than most budget alternatives. Step up to 275g/m² coating for permanent seaside exposure.
Color holds its shine through decades of sunlight We apply premium UV-stable PE paint that bonds tightly to the metal base. Panels retain over 90% original gloss after a full decade outdoors. We stock all standard RAL hues and can match custom color samples to fit architectural designs perfectly.
Corrugated structure balances sturdiness and quick fitting Wave, T-shape and glazed tile profiles are all available. The raised wave evenly spreads wind and snow loads, so standard roofs rarely need extra steel support. Crews cut and bend sheets easily onsite, cutting total build time and labor spend significantly.
Low maintenance, fully recyclable for green builds The reflective top layer cuts solar heat absorption, lowering indoor cooling costs. Once installed correctly, no regular repainting or anti-rust touch-ups are required. The entire steel panel is 100% recyclable, meeting global sustainable construction standards.
Performance Characteristics
Weather Resistance: Excellent performance against rain, wind, and temperature fluctuations
Thermal Efficiency: Reflective coating helps reduce heat absorption and energy costs
Impact Resistance: Withstands hail impact and other physical stresses
Fire Resistance: Non-combustible material enhances building safety
Sound Insulation: Reduces noise transmission from rain and external sources
Formability: Excellent bending and forming properties for diverse applications
Environmental Friendly: 100% recyclable material with sustainable production process
Application Range
Coastal port & bonded warehouses Ideal for permanent roofing of port logistics warehouses and bonded storage facilities in high-salt coastal regions. The 0.12mm aluzinc color-coated steel delivers reliable salt-spray and humidity resistance, standing up to airborne sea salt and frequent coastal rainfall without premature rusting. Its lightweight corrugated design reduces structural load, speeds up on-site installation and lowers construction labor costs.
Agricultural & aquaculture storage facilities Well-suited for seaside aquaculture cold sheds, agricultural material warehouses and marine feed storage yards. The PPGL surface resists mild chemical corrosion from farming supplies and damp sea air, while the corrugated profile ensures rapid rainwater drainage to avoid water pooling during typhoon and monsoon seasons with minimal long-term maintenance.
Temporary industrial storage & plant expansions Practical for temporary raw material storage canopies, workshop extensions and prefab storage yards at coastal processing plants. The 0.12mm thin-gauge sheet cuts overall project costs, requires only light supporting frameworks, and supports easy disassembly and reuse for future site layout adjustments, flexible for changing operational needs.
Technical Specifications
|
Parameter |
Specification |
|
Product Type |
Corrugated PPGL Color Coated Roofing Sheet |
|
Thickness Range |
0.09mm - 3.0mm |
|
Effective Width |
40 - 1250mm |
|
Coating Weight |
20 - 275 g/m² |
|
Coating Type |
PE, SMP, PU, HDP, PVDF, SRP, etc |
|
Coating Thickness |
Primer 8-30μm, Top Coat 5-30μm |
|
Color Options |
Full RAL Color Range + Custom Colors |
|
Profile Types |
Wave, T-shape, Glazed Tile, Custom Profiles |
Production Process
1. Raw Material Inspection - Comprehensive quality verification of incoming steel substrates
2. Surface Preparation - Thorough cleaning and pretreatment for optimal coating adhesion
3. Aluzinc Coating Application - Continuous hot-dip coating process for uniform protection
4. Primer Coating - Application of corrosion-inhibiting primer layer
5. Finish Coating - Precision application of colored top coat with consistent thickness
6. Curing Process - Controlled temperature curing for optimal coating performance
7. Corrugation Forming - Precision roll forming to create the corrugated profile
8. Quality Control - Multi-point inspection including coating weight, color match, and dimensional accuracy
9. Cutting & Sizing - Precision cutting to customer-specified dimensions
10. Final Inspection & Packaging - Comprehensive final check before packaging

Products Description
Color coated surfaces scratch easily, so we use custom protective packaging exclusive to PPGL panels. Separator paper sits between every sheet, wrapped in thick waterproof film, secured with steel corner guards and heavy strapping to survive long ocean transit. We ship out of Qingdao and Tianjin Port, supporting FCL full containers and smaller LCL orders. Standard stock ships in 8–14 days; custom color or profile orders take 15–20 days. We prepare complete export paperwork and share live cargo tracking links for all shipments.



Quality Certification
Our manufacturing facilities operate under internationally recognized quality management systems. We maintain rigorous quality control protocols throughout every production stage, from raw material selection to final inspection. Every product batch undergoes comprehensive testing to ensure consistent performance and adherence to strict quality standards. Our commitment to quality excellence ensures reliable products that meet global construction requirements.
• ISO 9001 Quality Management System Certification
• Comprehensive In-House Testing Facilities
• Regular Third-Party Quality Audits
• Strict Batch Traceability System
• Continuous Process Improvement Program

Company Support
Technical Support & Consultation
Our experienced technical team provides comprehensive support throughout your project lifecycle. We offer expert consultation on product selection, specification optimization, and installation guidance. Custom solution development is available for unique project requirements, ensuring you receive the most suitable products for your specific application.
Customization Services
We offer extensive customization capabilities including custom color matching, special profile development, and dimension customization to meet your exact project requirements. Our flexible production capabilities enable us to accommodate both standard specifications and custom orders efficiently.
After-Sales Service
We are committed to complete customer satisfaction through responsive after-sales support. Our dedicated service team addresses any inquiries promptly, providing technical assistance, warranty support, and resolution of any issues that may arise. We maintain long-term partnerships with our clients, ensuring ongoing support for all your roofing needs.
FAQ
18 to 25 years with 180–275g/m² heavy coating, far longer than standard PPGI roofing that degrades quickly in salt air.
PE suits inland sites for 10–15 year service life. PVDF delivers top-tier UV and corrosion resistance, perfect for coasts or heavy industrial zones with up to 25 years lifespan.
The minimum order quantity is one container; free A4-sized sample color swatches are available, with the buyer responsible only for shipping costs.
We offer secure T/T transfers and irrevocable sight L/C for global buyers. Long-term repeat partners can discuss adjusted flexible terms.
Light foot traffic is okay with proper plywood support; we share full load and walking safety notes inside our installation manual.
